DMC950 Compact
DMC m950 is the compact deburring-finishing machine designed to meet a variety of production requirements for diversified machining. The machine allows to better satisfy all dry deburring and satinising requirements of metallic surfaces thanks to the several customising machine configurations and the technical features of the working units.
Description
Advantages
“ON FLY” ABRASIVE BELT CENTERING
The oscillating system for the belt tensioner roller works with an extremely precise and reactive “background suppression”, to guarantee always the proper belt centering with rotation speed up to 40 m/s.
5 SECONDS TO REPLACE A VERTICAL BRUSH
The “Quick lock” conical couplings allow you to quickly set up the machine for any type of application, while ensuring maximum locking safety.
LONG IS BETTER: BELTS WITH 2620 mm LENGTH FOR LONGER LIFETIME
Longer abrasive belts improve the cooling of the abrasive grains, thus facilitating the detachment of the processing powders. A longer belt has a 43% longer lifetime, requires less replacements and therefore less downtime.
EASY: SIMPLE AND SAFE TO USE FOR EVERY APPLICATION
The complete range of devices and advanced technological solutions allow to satisfy the different production needs for small batches, such as deburring, oxide removal from edges and surface finishing.
Technical data
| Number of operating units | 2 – 3 | |
| Working width | mm | 950 |
| Min/max standard working thickness (mobile worktable) | mm | 0,5 ÷ 170 |
| Min/max standard working thickness (fixed worktable) | mm | 0,5 ÷ 200 |
| Sanding belt dimensions | mm | 970×260 |
| Fixed height worktable | mm | 900 |
| Mat feed speed | m/min | 0,5 ÷ 10 |
